STARRETT COMBINATION SQUARE SET WITH VERNIER

Description

9ME-300 300mm (11.3/4″) Steel Combination Set



This combination set with square includes a reversible lock bolt, scriber and spirit level in both square head and protractor head. Its cast iron head features a black wrinkle finish, while the blade is available with either a satin chrome or regular finish.



Features:

• Reversible lock bolts, scriber, spirit level in both square head and protractor head
• Direct reading double 180º protractor scale
• Non-reversible protractor head
• Hardened steel, photo-engraved blade
• Cast iron heads with black wrinkle finish



Specifications:

• Type: Steel Combination Set
• Blade Length: 300mm (11.3/4”)
• Blade Finish: Regular
• Graduation Type: 36
• Graduations: 1/2mm and 32nds one side; mm and 64ths reverse side
• Head Finish: Black wrinkle
• Head Material: Cast iron
• Head Types: Square, Centre, Protractor
• Number of Pieces: 4
• Protractor Type: Non-reversible
• Packaging: Case



---

EC799AF-4/100 – Fractional Display Caliper



The EC799AF Fractional Caliper is lightweight, comfortable, and easy to use. Made from hardened stainless steel, it has a slim profile and a clear LCD display. The display includes function buttons for zeroing and unit switching (mm, inch, F).



Features:

• Lightweight, ergonomic design
• Millimetre/inch/fraction conversion – reads 0.01 mm, .0005″ or 1/64″
• Auto-off after 5 minutes
• Durable and hardened stainless steel body
• Fine adjustment thumb wheel
• Lock screw to secure slide position
• Zero setting at any position
• Maximum measuring speed: 1.5m/sec or 60″/sec
• Battery: Single SR44/LR44 long-life battery; low battery warning with flashing display
• Comes with a battery cover wrench for easy access
• USB port for data output
• Conforms to DIN862 standard
• Comes with a hardwearing case



Specifications:

• 0 – 100mm / 0 – 4″
• 0.01mm / .0005″ / 1/64″
•  MTS**
• Country of origin: China
